1
2
3
4
5
6
7
9
9-1
9-2
9-3
9-4
9-5
9-6
9-7
9-8
9-10
9-11
15
10
11
12
13
14
16
17
18
19
20
22
23
24
24-1
24-2
24-3
25
26
27
27-1
28
29
30
31
31-1
31-2
31-3
31-4
32
33
34
35
36
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
0303dp 用量 (number of 0303dp used) |
|---|---|---|---|---|---|
| 1 | pf03030101 | 面板（毛坯） | 1 | ||
| 2 | pf0302111 | 面板螺钉 | 3 | ||
| 3 | pf03030103 | 面板线勾 | 1 | ||
| 4 | pf03030104 | 线勾 | 1 | ||
| 5 | pf6150106 | 面板线勾螺钉 | 3 | ||
| 6 | pf6150113 | 三眼线勾 | 1 | ||
| 7 | pf68425h33 | 螺钉 | 1 | ||
| 9 | pf03030109q | 夹线器组件（灰） | 1 | ||
| 9-1 | pf03030109q01 | 夹线螺钉 | 1 | ||
| 9-2 | pf03030109q02 | 夹线螺母 | 1 | ||
| 9-3 | pf03030109q03 | 夹线弹簧 | 1 | ||
| 9-4 | pf03030109q04 | 松线板 | 1 | ||
| 9-5 | pf03030109q05 | 夹线板 | 2 | ||
| 9-6 | pf03030109q06 | 挑线簧 | 1 | ||
| 9-7 | pf03030109q07 | 夹线调节座 | 1 | ||
| 9-8 | pf03030109q08 | 夹线调节座螺钉 | 1 | ||
| 9-10 | pf03030109q10 | 夹线螺母止动板 | 1 | ||
| 9-11 | pf03030109q11 | o型圈 | 1 | ||
| 15 | pf0303010909 | 松线钉 | 1 | ||
| 10 | pf555029 | 上轴后轴套螺钉gs0549 | 1 | ||
| 11 | pf03030111 | 挑线杆防护罩(镀铬） | 1 | ||
| 12 | pf6150211 | 挑线杆防护罩螺钉 | 1 | ||
| 13 | pf0302113 | 三眼线勾 | 1 | ||
| 14 | pf5550317 | 右线钩螺钉gs0552 | 1 | ||
| 16 | pf6150712 | 松线杆 | 1 | ||
| 17 | pf6150104 | 面板橡皮塞φ11.8 | 1 | ||
| 18 | pf03030118 | 夹具座 | 1 | ||
| 19 | pf5550117 | 卷边器座螺钉 sm11/64″*40 l=5 | 2 | ||
| 20 | pf6150142 | 底板撑杆(长) | 4 | ||
| 22 | 330303020101 | 0303dp机头加工后 | 1 | ||
| 23 | 340303010101 | 0303e底板加工后 | 1 | ||
| 24 | pf0302cx143 | 推板组件 | 1 | ||
| 24-1 | pf0302cx0139 | 推板 | 1 | ||
| 24-2 | pf0302cx014301 | 推板簧 | 1 | ||
| 24-3 | pf0302cx014302 | 推板簧螺钉 | 2 | ||
| 25 | pf0302141 | 针板m2.6 | 1 | ||
| 26 | pf5550637 | 针板螺钉gs044 | 2 | ||
| 27 | pf03030127 | 绕线器组件 | 1 | ||
| 27-1 | pf03030127sf01 | 绕线器橡胶圈 | 1 | ||
| 28 | pd-0128 | 绕线器固定螺钉(0303) | 3 | ||
| 29 | pf90000132 | 绕线切刀 | 1 | ||
| 30 | pf555068 | 送料连杆销螺钉gs0560 | 2 | ||
| 31 | pf03030131 | 绕线器小夹线器组件（白66#） | 1 | ||
| 31-1 | pf0303013105 | 绕线器小夹线器螺母 | 1 | ||
| 31-2 | pf0303013106 | 绕线器小夹线器弹簧 | 1 | ||
| 31-3 | pf0303013103 | 绕线器小夹线器夹线板 | 2 | ||
| 31-4 | pf0303013104 | 绕线器小夹线器螺钉 | 1 | ||
| 32 | pf555029 | 上轴后轴套螺钉gs0549 | 1 | ||
| 33 | pf03030137 | 绕线器橡胶垫 | 1 | ||
| 34 | 12010122fwa | 电控箱 | 1 | ||
| 35 | scj2011 | 内六角螺钉 | 3 | ||
| 36 | 12020009 | 面板组件 | 1 |
