操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
---|---|---|---|---|
1 | bf7201738 | 缝制平台(电切)(毛坯) | ||
2 | scj2002 | 内六角螺钉 | ||
3 | bf7870203 | 螺丝(m4-0.7x7) | ||
4 | bf7200204 | 曲轴室上盖 | ||
5 | bf7200205 | 曲轴室垫片 | ||
6 | bf7870107 | 止油胶塞 | ||
7 | bf8007019 | 螺钉m4x8 | ||
8 | bf7870208 | 后盖(毛坯) | ||
9 | bf7870209 | 后盖垫片 | ||
10 | bf7200210 | 一字沉头螺丝(m3-0.5×10) | ||
12 | bf7870212 | 滑件辅助盖(毛坯) | ||
13 | bf7870213 | 垫片 | ||
14 | bf310167009 | 螺钉 | ||
15 | bf7200215 | 针板座 | ||
16 | bf7870216 | 顶出销 | ||
17 | bf310167021 | 螺钉m4x12 | ||
18 | bf7870218 | 螺丝(m3-0.5x6.5) | ||
19 | bf7870219 | 定位衬套 | ||
20 | bf7870220 | 顶出销 | ||
24 | bf7200224 | 前盖底座(毛胚) | ||
25 | bf7870225 | 螺丝(m4-0.7x8) | ||
26 | bf7870226 | 锥形弹簧垫圈 | ||
27 | bf7870227 | 螺丝(m4-0.7x13) | ||
28 | bf7801449 | 前盖铰链 | ||
29 | bf310164543 | 螺钉m4x4 | ||
30 | bf310167025 | 螺钉 | ||
31 | bf7200231 | 前盖顶座(毛坯) | ||
32 | bf7870232 | 螺丝(m4-0.7x6) | ||
33 | bf7870114 | 锁闩弹簧 | ||
34 | kb3036 | 铆钉 | ||
35 | bf7870235 | 螺丝(m4-0.7x8) | ||
36 | bf7870236 | 螺丝(m4-0.7x4.5) | ||
37 | bf7870237 | 锁闩弹簧 | ||
39 | bf7200239 | 侧盖锁门磁铁吸 | ||
40 | bf7870240 | 底线分线盘凸轮盖组 | ||
41 | bf7870241 | 警告贴纸(四角形) | ||
42 | bf7870238 | 底线分线盘驱动室盖(毛坯) | ||
44 | bf7870244 | 螺帽 | ||
45 | bf7870245 | 螺丝(m4-0.7x8) | ||
46 | bf7870232 | 螺丝(m4-0.7x6) | ||
47 | bf7870247 | 底线分线盘凸轮盖(毛坯) | ||
48 | bf7870133 | 警告贴纸(三角形) | ||
49 | bf7870241 | 警告标贴 | ||
50 | bf7870249 | 螺丝(m4-0.7x3.5) | ||
51 | bf7200251 | 内六角沉头螺丝(m3-0.5×10) | ||
52 | bf7200252 | 针板支架 | ||
53 | bf7870257 | 下切刀托架导引片 | ||
54 | pf1310d205 | 螺钉 m4×4 | ||
55 | bf7871622 | 底线过线护槽 | ||
56 | pf1790s0856 | 挡线钩螺钉 | ||
57 | bf7200257 | 前盖底座组 | ||
58 | bf7870259 | 底线穿线孔 | ||
59 | bf7200259 | 针板支架组 | ||
60 | bf7871009 | 螺丝(m3-0.5x3) | ||
61 | bf310164543 | 螺钉m4x4 | ||
62 | bf7200262 | 型号铭牌 |
