1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
47
48
49
50
51
52
53
63
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
|---|---|---|---|---|
| 1 | bf7870301 | 上线张力弹簧调整钮（蓝） | ||
| 2 | bf7870302 | 张力弹簧调整圆盘 | ||
| 3 | bf7870303 | 针线张力弹簧 | ||
| 4 | bf7870304 | 上饰线张力弹簧 | ||
| 5 | bf7870305 | 下勾针张力弹簧 | ||
| 6 | bf7870306 | 上线张力弹簧固定座 | ||
| 7 | bf7870307 | 毡垫 | ||
| 8 | bf7870308 | 张力调整盘 | ||
| 9 | bf7870309 | 上线张力弹簧支柱 | ||
| 10 | bf7870310 | 上线张力弹簧支柱套圈 | ||
| 11 | bf7870311 | 上线张力圆盘分离器 | ||
| 12 | bf7870312 | 上线张力组支柱座 | ||
| 13 | bf7870313 | 过线导管固定座 | ||
| 14 | bf7870229 | 螺丝（m4-0.7x4） | ||
| 15 | bf7870125 | 螺丝（m4-0.7x8） | ||
| 16 | bf7870316 | 上饰线过线杆（左） | ||
| 17 | bf7870317 | 陶瓷过线孔 | ||
| 18 | bf7870318 | 螺丝（sm1/8 | ||
| 19 | bf7870319 | 螺丝（sm1/8 | ||
| 20 | bf7870320 | 过线导管（长） | ||
| 21 | bf7870321 | 过线导管（短） | ||
| 22 | bf7870322 | 上饰线过线杆（右） | ||
| 23 | scj3010 | 平垫圈 | ||
| 24 | bf7870324 | 矽油槽盖 | ||
| 25 | bf7870325 | 矽油储存槽 | ||
| 26 | bf7870326 | 吸油毡 | ||
| 27 | bf7870327 | 针线过线架 | ||
| 28 | bf7870328 | 矽油槽盖固定插销 | ||
| 29 | bf7870329 | 过线杆固定座 | ||
| 30 | bf7870330 | 过线杆 | ||
| 31 | bf7870331 | 针线矽油组 | ||
| 32 | bf7870102 | 螺丝（m4-0.7x12） | ||
| 33 | bf7870333 | 螺丝（sm9/64 | ||
| 34 | bf7870334 | 矽油储存槽组件 | ||
| 35 | bf7870335 | 上饰组板组件 | ||
| 36 | bf7870336 | 上线张力支柱座组件 | ||
| 37 | bf7870337 | 固定插销 | ||
| 38 | scj4024 | 开口销 | ||
| 39 | bf7870339 | 针线导架 | ||
| 40 | bf7870340 | 针线提线杆护架 | ||
| 41 | bf7870341 | 螺丝（m6-1x10） | ||
| 42 | bf7870342 | 针线张力调整组固定座（小） | ||
| 43 | bf7870343 | 上线张力弹簧调整钮（红） | ||
| 44 | bf7870344 | 上线张力支柱座 | ||
| 47 | bf7870347 | 上饰线导板 | ||
| 48 | bf7870348 | 上饰线辅助导板 | ||
| 49 | bf7870349 | 上饰线张力调整组支柱 | ||
| 50 | bf7870350 | 上饰线张力调整盘 | ||
| 51 | bf7870351 | 上饰线张力调整弹簧 | ||
| 52 | bf7870352 | 松紧调钮 | ||
| 53 | bf7870353 | 过线导片 | ||
| 63 | bf7870363 | 过线陶瓷（深灰） |
