1
2
3
4
5
6
7
10
12
13
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42-1
42-2
43
44
46
47
48
49
53
54
56
57
58
59
60
61
62
63
64
65
66
67
5
5
6
28
20
46
17
48
39
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
q6lte 用量 (number of q6lte used) |
|---|---|---|---|---|---|
| 1 | pfq5te20101l | 面板 | 1 | ||
| 2 | pfq5te20102 | 面板垫 | 1 | ||
| 3 | pf5550824 | 油窗 | 1 | ||
| 4 | pf5550825 | 油窗o形圈 | 1 | ||
| 5 | pf5550113 | 挑线连杆销螺孔塞(8.7) | 4 | ||
| 6 | pf5550112 | 针杆曲柄螺孔塞 | 2 | ||
| 7 | pf555016 | 后窗板螺钉gs053 | 9 | ||
| 10 | pfq5110 | 三眼线钩 | 1 | ||
| 12 | pf5550115 | 下轴盲孔塞 | 1 | ||
| 13 | bz3097 | 型号牌 | 1 | ||
| 16 | pf99901511 | 线夹u2 | 2 | ||
| 17 | pf5550161 | 后盖板加长螺钉 | 3 | ||
| 18 | pf99901160 | 线夹u3 | 1 | ||
| 19 | pfq70120 | q7底板支柱2 | 1 | ||
| 20 | pfq70119 | q7底板支柱1 | 3 | ||
| 21 | scj6071 | 铆钉 | 2 | ||
| 22 | pf90000131 | 绕线器紧固螺钉 | 3 | ||
| 23 | pf90000132 | 绕线切刀 | 1 | ||
| 24 | pf68425k19 | 油线支架螺钉 | 2 | ||
| 25 | pf5550230 | 挑线杆护罩螺钉gs0551 | 1 | ||
| 26 | pfq5126 | 挑线杆护罩（电镀） | 1 | ||
| 27 | pf5550316 | 右线钩 | 1 | ||
| 28 | pf5550317 | 右线钩螺钉gs0552 | 2 | ||
| 29 | pf9520mxdk021 | 大线钩组件 | 1 | ||
| 30 | pf555063601d | 针板(四排φ1.8) | 1 | ||
| 31 | pf5550637 | 针板螺钉gs044 | 2 | ||
| 32 | pfq50132 | 夹具座 | 1 | ||
| 33 | pf5550117 | 卷边器座螺钉 sm11/64″*40 l=5 | 1 | ||
| 34 | pf5550638 | 推板部件 | 1 | ||
| 35 | pf5550639 | 推板 | 1 | ||
| 36 | pf5550640 | 推板簧 | 1 | ||
| 37 | pf5550641 | 推板螺钉 | 2 | ||
| 38 | pf5550161 | 后盖板加长螺钉 | 3 | ||
| 39 | pf8420m-d3010107 | 橡皮塞 | 2 | ||
| 40 | bz3314 | 面板装饰牌(背胶亮面） | 1 | ||
| 41 | pfq5141 | 绕线夹线器（灰帽） | 1 | ||
| 42 | pf90000157 | 绕线器组件 | 1 | ||
| 42-1 | pf900001511 | 绕线器垫片油封 | 1 | ||
| 42-2 | pf90000157sf01 | 橡胶轮 | 1 | ||
| 43 | bz3141 | 黄底警告标贴 | 1 | ||
| 44 | pfq6lte30144c | 电控组件 | 1 | ||
| 46 | pfq5te20146 | 电机罩固定螺钉（长m4-40） | 3 | ||
| 47 | pfq6lte30144c02 | 操作屏面板 | 1 | ||
| 48 | bf310164527 | 螺钉 | 4 | ||
| 49 | pf1310c227 | 螺钉 m4x10 | 4 | ||
| 53 | pf98000187 | 偏心轮调节孔塞 | 1 | ||
| 54 | pfq6l0154 | 左线钩 | 1 | ||
| 56 | pf9520mxdk02101 | 缓线勾紧固螺母 | 1 | ||
| 57 | pfq5te20157 | 面板固定块i | 1 | ||
| 58 | pfq5te20158 | 面板固定块ii | 1 | ||
| 59 | scj5063 | 电线夹 #12(rohs) | 2 | ||
| 60 | pf1310d239 | 螺钉 | 2 | ||
| 61 | pfq90a015902 | 油窗下体 | 1 | ||
| 62 | pfq90a0163 | o型圈 | 1 | ||
| 63 | pfq90a015901 | 油窗上体 | 1 | ||
| 64 | pf9820a50 | 橡皮塞4 | 1 | ||
| 65 | pf900081412 | 1/8*44-6内止螺丝 | 1 | ||
| 66 | bf7005292 | 螺钉 | 1 | ||
| 67 | pf90008108 | 分线器固定螺钉 | 1 | ||
