| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
2290 用量 (number of 2290 used) |
|---|---|---|---|---|---|
| 01 | pf22840103 | 面板组件 face plate compl. | 1 | ||
| 02 | pf22900102 | 后盖板 side plate | 1 | ||
| 03 | pf22900103 | 前支脚 bed support plate | 1 | ||
| 04 | pf22900104 | 后支脚 bed support plate b | 1 | ||
| 05 | pf22900105 | 松线杆 thread release auxiliary pin | 1 | ||
| 06 | pf22840124 | 中过线器组件 prk-tension controller asm. | 1 | ||
| 26 | pf22900126 | 后罩 pulley cover | 1 | ||
| 27 | pf1900a0256 | 后罩螺钉 bolt | 4 | ||
| 28 | pf22900128 | 橡胶盖 air-discharging cap | 1 | ||
| 29 | pf22900129 | 透气阀 air-dischakging | 1 | ||
| 30 | pf22840117 | 面板刀片 take-up thread cutter | 1 | ||
| 31 | pf2284014701 | 摆动架槽框 arm oil shield | 1 | ||
| 32 | pf22900132 | 复位螺钉 suspension screw | 1 | ||
| 33 | bf700n03 | 复位螺母 nut 11/64-40 | 1 | ||
| 34 | pf22840106 | 密封垫片 gasket | 1 | ||
| 35 | / | 警告牌 attention seal | 1 | ||
| 36 | pf22840136 | 油塞 driv1ng stopper rubber | 2 | ||
| 37 | pf22900137 | 透气阀o型圈 rubber ring | 1 | ||
| 38 | pf22900138 | 夹线器o型圈 rubber ring | 1 | ||
| 39 | pf22900139 | 透气阀弹簧销 spring pin 8x20 | 1 | ||
| 40 | pf22840129 | 护盖罩窗螺钉 hinge screw d= 6.35 h= 7.5 | 1 | ||
| 42 | pf5550637 | 面板螺钉 screw 11/64-40 l=8 | 7 | ||
| 43 | pf22840133 | 导线架螺钉 screw 9/64-40 l=7.2 | 1 | ||
| 44 | pf22840132 | 护盖螺钉 screw 11/64-40 l=9 | 2 | ||
| 45 | pf22840107 | 挑线盘防护盖 balance cover base | 1 | ||
| 46 | pf5550230 | 螺钉 sckew 3/16-28 l=io | 4 | ||
| 47 | pf5550230 | 护盖弹簧片螺钉 screw 3/16-28 l=6 | 1 | ||
| 48 | pf555016 | 后盖板螺钉 screw 3/16-28 l=10 | 4 | ||
| 50 | pf7810239 | 前支脚螺钉 screw 15/64 -28 l=9 | 4 | ||
| 51 | pf22840108 | 挑线盘防护罩组件 balance cover | 1 | ||
| 52 | pf22840104 | 面板垫 face plate packing | 1 | ||
| 53 | pf22840128 | 面板刀片螺钉 screw 1/8-44 l= 3.8 | 1 | ||
| 54 | pf22840105 | 油窗板 thread release window plate | 1 | ||
| 56 | pf22900156 | 摆动架销油塞 plug d=8 l=4.5 | 1 | ||
| 57 | pf22900157 | 油塞 rubber plug d=12.5 l=4 | 1 | ||
| 58 | pf22900158 | 顶油塞 rubber plug d=12.5 l=4 | 3 | ||
| 60 | pf22840131 | 护盖罩窗垫片 washer 6.5x11x1 | 1 | ||
| 62 | pf22840130 | 护盖罩窗弹簧片 waved washer 6.4x11x0.3 | 1 | ||
| 65 | pf22900165 | 护目镜 safety plate | 1 | ||
| 66 | pf22900166 | 护目镜安装支架 support balance base | 1 | ||
| 67 | pf22900167 | 护目镜安装板 mounting base | 1 | ||
| 68 | pf22840304 | 螺钉 screw 11/64-40 l=9 | 1 | ||
| 69 | pf5550312 | 螺钉 screw 9/64-40 l= 5.0 | 1 | ||
| 70 | pf555068 | 螺钉 screw 1/8-40 l=7 | 1 | ||
| 71 | / | 垫片 washer 3.3x6x0. 5 | 2 | ||
| 72 | pf22900172 | 夹线器组件 thread tension asm. a | 1 | ||
| 73 | pf22900173 | 夹线器组件 thread tension asm. b | 1 | ||
| 74 | pf22900174 | 松线板 tension disc holder | 1 | ||
| 75 | pf22900175 | 挑线簧 thread take-up spring | 1 | ||
| 76 | pf22900176 | 夹线板组件 thread tension t compl. | 1 | ||
| 77 | pf22900177 | 夹线板组件 felt | 4 | ||
| 78 | pf22900178 | 夹线螺母制动垫圈 rotation stopper | 1 | ||
| 79 | pf22900179 | 夹线器座组件 thread tension rod base asm. | 1 | ||
| 80 | pf22900180 | 夹线螺钉组件 thread tension rod compl. | 1 | ||
| 81 | pf22900181 | 松线钉 thread release pin | 1 | ||
| 82 | pf22900182 | 夹线螺母 thread tension nut | 1 | ||
| 83 | pf22900183 | 夹线簧 tension spring | 1 | ||
| 84 | pf22900184 | 夹线黄 tension spring | 1 | ||
| 85 | pf22900185 | 夹线螺钉固定螺钉 screw 9/64-40 l= 5.5 | 1 | ||
| 86 | pf22840115 | 橡皮塞 rubber plug | 1 | ||
| 87 | pf22900187 | 毛毡 felt | 1 | ||
| 88 | pf22900188 | 压簧 felt presser | 1 | ||
| 89 | pf5550317 | 螺钉 screw 11/64-40 l=6 | 1 | ||
| 90 | pf22900190 | 松线杆复位弹簧 thread release pik spring | 1 | ||
| 91 | pf20521123 | 夹线器固定螺钉 screw ll/64-40 l= 6.5 | 1 | ||
| 92 | pf22840114 | 导线架 balance thread guide b | 1 | ||
| 93 | pf22840109 | 护盖弹簧片 balance coyer stopper spring | 1 |
