01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
2284 用量 (number of 2284 used) |
|---|---|---|---|---|---|
| 01 | 操作图章 operation seal | 1 | |||
| 02 | pf22840102 | 机壳前盖板垫 gasket | 1 | ||
| 03 | pf22840103 | 面板 face plate compl. | 1 | ||
| 04 | pf22840104 | 面板垫 gasket of face plate | 1 | ||
| 05 | pf22840105 | 松线窗盖板 tension release window plate | 1 | ||
| 06 | pf22840106 | 松线窗盖板垫 gasket | 1 | ||
| 07 | pf22840107 | 平盖底座 balance cover base | 1 | ||
| 08 | pf22840108 | 平盖 balance cover | 1 | ||
| 09 | pf22840109 | 弹簧片 spring | 1 | ||
| 10 | 警告标牌 attention seal | 1 | |||
| 11 | pf22840111 | 挑线簧防护架 spring guard | 1 | ||
| 12 | pf19000752 | 导线板螺钉 screw 11/64-40 l=8 | 2 | ||
| 13 | pf22840113 | 导线柱 thread guide pin | 1 | ||
| 14 | pf22840114 | 面板线勾 spring guard | 1 | ||
| 15 | pf22840115 | 橡皮塞 rubber plug | 1 | ||
| 16 | pf22840716 | 橡皮塞 rubber plug | 1 | ||
| 17 | pf22840117 | 挑线割线刀 take-up thread cutter | 1 | ||
| 18 | pf22840118 | 后盖板 side plate | 1 | ||
| 19 | pf22840119 | 后盖板垫 gasket | 1 | ||
| 20 | pf888056d112 | 示油窗 oil sight window | 1 | ||
| 21 | pf22840121 | 限位橡皮 rubber stopper | 1 | ||
| 22 | pf22840122 | 橡皮塞 plug d=8 l=4.5 | 1 | ||
| 23 | pf22840716 | 橡皮塞 rubber plug | 1 | ||
| 24 | pf22840124 | 预张力夹线器组件 pre-tension controller asm. | 1 | ||
| 25 | pf20521123 | 夹线器螺钉 screw 11/64-40 l=6.5 | 1 | ||
| 26 | pf2284050702 | 前盖板螺钉 screw 3/16-28 l=14 | 5 | ||
| 27 | pf5550637 | 面板螺钉 screw 11/64-40 l=8 | 7 | ||
| 28 | pf22840128 | 挑线割线刀螺钉 screw 1/8-44 l=3.8 | 1 | ||
| 29 | pf22840129 | 平盖铰链螺钉 hinge screw d=6.35 h=7.5 | 1 | ||
| 30 | pf22840130 | 波形垫圈 waved washer 6.4×11×0.3 | 1 | ||
| 31 | pf22840131 | 平盖铰链垫圈 washer 6.5×11×1 | 1 | ||
| 32 | pf22840132 | 平盖底座固定螺钉 screw 11/64-40 l=9 | 2 | ||
| 33 | pf22840133 | 面板线勾螺钉 screw 9/64-40 l=7 | 1 | ||
| 34 | pf5550230 | 松线窗盖板螺钉 screw 3/16-28 l=6 | 4 | ||
| 35 | pf5550230 | 弹簧片螺钉 screw 3/16-28 l=6 | 1 | ||
| 36 | pf22840136 | 橡皮塞 driving stopper rubber | 2 | ||
| 37 | pf22840115 | 橡皮塞 rubber plug | 1 | ||
| 38 | pf22840716 | 橡皮塞 plug | 1 | ||
| 39 | pf22840139 | 松线顶杆 thread release | 1 | ||
| 40 | pf22840140 | 导线板 balance thread guide | 1 | ||
| 41 | pf555016 | 后盖板螺钉 screw 3/16-28 l=10 | 1 | ||
| 42 | pf5550825 | 示油窗o形圈 rubber ring | 1 | ||
| 43 | pf22840143 | 挑线簧防护架螺钉 screw 9/64-40 l=3.5 | 1 | ||
| 44 | pf22840144 | 夹线器组件 thread tension asm. | 1 | ||
| 45 | pf22840145 | 夹线螺母 tension nut | 1 | ||
| 46 | pf22840146 | 夹线座螺钉 screw 9/64-40 l=5.5 | 1 | ||
| 47 | pf22840147 | 夹线螺母止动片 rotating stopper | 1 | ||
| 48 | pf22840148 | 松线钉 tension release pin asm. | 1 | ||
| 49 | pf22840149 | 夹线簧 tension spring | 1 | ||
| 50 | pf22840150 | 夹线盘组件 thread tension disk compl. | 1 | ||
| 51 | pf22840151 | 夹线座 thread tension rod asm. | 1 | ||
| 52 | pf22840152 | 挑线簧 take-up spring | 1 | ||
| 53 | pf22840153 | 夹线螺钉 thread tension post asm. | 1 | ||
| 54 | pf22840154 | 毛毡 felt | 2 | ||
| 55 | pf22840155 | 夹线板 tension disc holder | 1 | ||
| 56 | bz3095 | 型号牌 model plate | 1 | ||
| 57 | 铆钉 rivet | 2 | |||
| 58 | pf22840147 | 机壳 arm | 1 | ||
| 59 | pf22840148 | 底板 bed | 1 | ||
| 60 | pf2284014701 | 针杆摆动槽挡油板 arm oil shield | 1 | ||
| 61 | pf2284014801 | 送料摇杆支架 feed driving rocker support | 1 | ||
| 62 | pf22900167 | 护目镜安装板 guard view installing base | 1 | ||
| 63 | pf22900166 | 护目镜安装支架 guard view support | 1 | ||
| 64 | pf22900165 | 护目镜 guaer view | 1 | ||
| 65 | pf22840304 | 护目镜安装板螺钉 screw 11/64-40 l=7.8 | 2 | ||
| 66 | pf555068 | 护目镜安装支架螺钉 screw 1/8-44 l4.5 | 1 | ||
| 67 | 垫片 washer | 1 | |||
| 68 | pf5550312 | 护目镜螺钉 screw 9/64-40 l=6 | 1 |
