| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
|---|---|---|---|---|
| 01 | pf0303d0101l | 面板 face plate | ||
| 02 | pf0302111 | 面板螺钉 screw | ||
| 03 | pf03030103 | 面板线勾 thread guide | ||
| 04 | pf03030104 | 线勾 thread guide | ||
| 05 | pf6150106 | 线勾螺钉 screw | ||
| 06 | pf03030106q | 小夹线组件thread guide assy. | ||
| 06-1 | pf03030106q01 | 小夹线过线板thread guide | ||
| 06-2 | pf03030106q02 | 小夹线螺钉pre-tension stud | ||
| 06-3 | pf03030106q03 | 小夹线组板tension disc | ||
| 06-4 | pf03030106q04 | 小夹线弹簧tension spring | ||
| 06-5 | pf03030106q05 | 小夹线螺母adjusting screw | ||
| 07 | pf68425h33 | 小夹线器固定螺钉set screw | ||
| 08 | pf0302157 | 下线勾thread guide | ||
| 09 | pf03030109q | 夹线组件 thread tension bracket assy | ||
| 09-1 | pf03030109q01 | 夹线螺钉 tension stud | ||
| 09-2 | pf03030109q02 | 夹线螺母 tension nut | ||
| 09-3 | pf03030109q03 | 夹线弹簧 tension sorina | ||
| 09-4 | pf03030109q04 | 松线板disc presser | ||
| 09-5 | pf03030109q05 | 夹线板disc, tension | ||
| 09-6 | pf03030109q06 | 挑线簧thread take-up spring | ||
| 09-7 | pf03030109q07 | 夹线调节座 thread tension bracket | ||
| 09-8 | pf03030109q08 | 夹线调节座螺钉 set screw | ||
| 09-10 | pf03030109q10 | 夹线螺母止动板stopper | ||
| 09-11 | pf03030109q11 | o型圈o ring | ||
| 10 | pf6150132 | 夹线调节座固定螺钉set screw | ||
| 11 | pf03030111 | 挑线杆防护罩 cover | ||
| 12 | pf6150211 | 挑线杆防护罩螺钉 screw | ||
| 13 | pf0302113 | 三眼线勾 thread retainer | ||
| 14 | pf6150114 | 三眼线勾螺钉 screw | ||
| 15 | pf6150131 | 松线钉tension release pin | ||
| 16 | pf6150712 | 松线棒tension release stud | ||
| 17 | pf6150104 | 橡皮塞rubber plug | ||
| 18 | pf03030118 | 夹具座ruler plate | ||
| 19 | pf5550117 | 夹具座螺钉screw | ||
| 20 | pf6150142 | 底板撑杆 bed leg | ||
| 21 | pf03030121 | 底板撑杆弹簧垫片 washer, spring | ||
| 22 | 033202010 | 机壳 arm | ||
| 23 | 034204015 | 底板 bed | ||
| 24 | pf0302cx143 | 推板组件 slide plate assy. | ||
| 24-1 | pf0302cx14301 | 推板 slide plate | ||
| 24-2 | pf0302cx14302 | 推板簧push the spring | ||
| 24-3 | pf0302cx14303 | 推板簧螺钉screw | ||
| 25 | pf0302141 | 针板 needle plate | ||
| 27 | pf03030127 | 绕线器组件winding device assembly | ||
| 28 | pd-0128 | 绕线器组件固定螺钉screw | ||
| 29 | pf90000132 | 切刀 sutting knife | ||
| 30 | pf555068 | 切刀螺钉 screw | ||
| 31 | pf03030131q | 绕线器小夹线器组件thread guide assy. | ||
| 32 | pf555029 | 小夹线器固定螺钉 screw | ||
| 33 | pf03030137 | 绕线器橡胶垫 washer | ||
| 34 | pf0303025501 | 电控箱operation panel | ||
| 35 | pf0303025501 | 电控箱operation panel | ||
| 26 | pf6150138 | 针板螺钉 screw | ||
| 36 | 13010044 | 六代一体操控盒pcb（成品） |
