01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42-1
43
44
45
47
48
49
50
51
52
53
54
05
05
06
17
28
28
38
39
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
q5t 用量 (number of q5t used) |
|---|---|---|---|---|---|
| 01 | pfq511 | 面板 face plate | 1 | ||
| 02 | pfq512 | 面板垫 face plate gasket | 1 | ||
| 03 | pf5550824 | 油窗 oil window | 1 | ||
| 04 | pf5550825 | 油窗o型圈 thrust collar asm | 1 | ||
| 05 | pf5550113 | 挑线连杆销螺孔塞 rubber plug | 3 | ||
| 06 | pf5550112 | 针杆曲柄螺孔塞 rubber plug | 2 | ||
| 07 | pf555016 | 后窗板螺钉 screw 3/16-28 l=9 | 8 | ||
| 08 | pfq518 | 后窗板 side plate | 1 | ||
| 09 | pfq519 | 后窗板垫 side plate gasket | 1 | ||
| 10 | pfq5110 | 三眼线勾 three eyeliner hook | 1 | ||
| 11 | pf5550114 | 送料调节器孔塞 rubber plug | 1 | ||
| 12 | pf5550115 | 下轴盲孔塞 rubber plug | 1 | ||
| 13 | pfq50113 | 型号牌 model plate | 1 | ||
| 14 | pf555013 | 底板支柱 bed screw stud | 2 | ||
| 15 | pf888056d131 | 电线过线套 needle bearing | 2 | ||
| 16 | pf99901511 | 电线压板（短） cord holder(s) | 2 | ||
| 17 | pf5550161 | 电线压板固定螺钉 screw 3/16-28 l=12 | 2 | ||
| 18 | pf99901160 | 电线压板（长） cord holder(l) | 1 | ||
| 19 | pf90000120 | 底板支柱（长） bed screw stud(l) | 1 | ||
| 20 | pf90000121 | 底板支柱（中） bed screw stud(m) | 1 | ||
| 21 | scj6071 | 型号牌铆钉 pole | 2 | ||
| 22 | pf90000131 | 绕线器紧固定螺钉 screw 3/16-32 l=7 | 3 | ||
| 23 | pf90000132 | 绕线切刀 thread cutter | 1 | ||
| 24 | pf68425k19 | 绕线切刀固定螺钉 screw 1/8-40 l=4 | 2 | ||
| 25 | pf5550230 | 挑线杆护罩螺钉 screw 3/16-28 l=6 | 1 | ||
| 26 | pfq5126 | 挑线杆护罩 thread take-up lever cover | 1 | ||
| 27 | pf5550316 | 右线钩 right arm thread guide | 1 | ||
| 28 | pf5550317 | 右线钩螺钉 screw 11/64-40 l=6 | 3 | ||
| 29 | pf9520mxdk021 | 大线钩 large arm thread guide | 1 | ||
| 30 | pf555063601b | 针板 needle plate | 1 | ||
| 31 | pf5550637 | 针板螺钉 screw 11/64-40 l=8.5 | 2 | ||
| 32 | pf03030118 | 卷边器座 ruler plate | 1 | ||
| 33 | pf5550117 | 卷边器座螺钉 screw 11/64-40 l=5 | 2 | ||
| 34 | pf5550638 | 推板组件 slide plate asm | 1 | ||
| 35 | pf555063801 | 推板 slide plate | 1 | ||
| 36 | pf555063802 | 推板簧 spring of slide plate | 1 | ||
| 37 | pf555063803 | 推板螺钉 screw | 2 | ||
| 38 | pf5550161 | 面板螺钉 screw 3/16-28 l=12 | 3 | ||
| 39 | pf5550111 | 面板调节螺孔塞 rubber plug | 2 | ||
| 40 | bz3188 | 面板装饰牌 plate | 1 | ||
| 41 | pfq5141 | 绕线夹线器组件 bobbin thread tension asm | 1 | ||
| 42 | pf90000157 | 绕线器 bobbin winder asm | 1 | ||
| 42-1 | pf900001511 | 绕线器油封 oil seal | 1 | ||
| 43 | bz3141 | 安全指示牌 safety-indicating plate | 1 | ||
| 44 | pfq3t0144a | 电机罩组件 pilley cover asm | 1 | ||
| 45 | pfs5t0149 | 电机罩组件固定螺钉（短） screw（ short） | 3 | ||
| 47 | pfq4t0147 | 操作面板组件 operation panel | 1 | ||
| 48 | pfq50148 | 操作面板组件固定螺钉 screw | 1 | ||
| 49 | pfq5149 | 支架固定螺钉 screw m4 l=5.5 | 2 | ||
| 50 | pfq5150 | 支架 stand | 1 | ||
| 51 | pfq5151 | 操作面板顶紧螺钉 screw m5 l=25 | 1 | ||
| 52 | pf98000187 | 调节孔孔塞 rubber plug | 1 | ||
| 53 | pfq5129 | 左线钩 left arm thread guide | 1 | ||
| 54 | pf9520mxdk02101 | 螺母 nut 11/64-40 | 1 |
