| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
640 用量 (number of 640 used) |
|---|---|---|---|---|---|
| 04 | pfpc0104 | 面板face plate | 1 | ||
| 05 | pf03030903 | 面板上螺钉 screw for face plate | 1 | ||
| 06 | pf0302111 | 面板下螺钉 screw | 2 | ||
| 07 | pfpc0107 | 挑线杆防护罩 thread take up cover | 1 | ||
| 08 | pf6150107 | 挑线杆防护罩螺钉 screw | 1 | ||
| 09 | pfpc0109 | 过线杆 upper thread guide pin ass'y | 1 | ||
| 10 | pfpc0110 | 过线杆螺母 nut for a-9 | 1 | ||
| 13 | pf03030106 | 小夹线器组件 sub upper thread tension ass'y control | 1 | ||
| 14 | pf68425h33 | 小夹线器支头螺钉 screw | 1 | ||
| 15 | pf03030104 | 机壳线勾 arm thread guide | 1 | ||
| 16 | pf6150106 | 机壳线勾螺钉 screw | 1 | ||
| 17 | pf03030103 | 面板线勾 face plate thread guide | 1 | ||
| 18 | pf6150106 | 面板线勾螺钉 screw | 1 | ||
| 27 | pfpc0127 | 上盖 top cover | 1 | ||
| 28 | pfpc0128 | 上盖密封垫 gasker for top cover | 1 | ||
| 29 | bf700s039 | 上盖螺钉 screw | 8 | ||
| 30 | pfpc0130 | 后前盖板 back cover | 1 | ||
| 31 | pfpc0131 | 后前盖板密封垫 gasker for backcover | 1 | ||
| 34 | pfpc0134 | 电磁铁盖板 b/t solenoid bracket | 1 | ||
| 35 | pfpc0135 | 电磁铁盖板密封垫 gasket for b/t solenoid bracket | 1 | ||
| 36 | pfpc0136 | 电磁铁连接垫板 gasket for b/t solenoid | 1 | ||
| 37 | pfpc0137 | 倒缝电磁铁组件 b/t solenoid ass'y | 1 | ||
| 38 | pf6150107 | 电磁铁连接螺钉 screw | 4 | ||
| 39 | bf700s039 | 后盖板螺钉 screw | 9 | ||
| 40 | pfpc0140 | 针板 needle plate | 1 | ||
| 41 | pf6150138 | 针板螺钉 screw | 2 | ||
| 42 | pfpc0142 | 推板 slide plate | 1 | ||
| 43 | pfpc0143 | 推板簧 slide plate spring | 1 | ||
| 44 | pfpc0144 | 推板簧螺钉 screw | 2 | ||
| 45 | pfpc0145 | 夹边座 gaure plate | 1 | ||
| 46 | pf6150138 | 夹边座螺钉 screw | 1 | ||
| 47 | pfpc0147 | 机头前支撑杆 bed base(front) | 2 | ||
| 48 | pfpc0148 | 机头后支撑杆 bed base(rear) | 2 | ||
| 49 | pfpc0149 | 面板下橡皮塞11.8 face plate rubber cap | 1 | ||
| 50 | pfpc0150 | 下轴后端橡皮塞24.6 bed rubber cap | 1 | ||
| 51 | pfpc0151 | 上盖橡皮塞19 top cover rubber cap | 2 | ||
| 52 | pfpc0152 | 压脚摆动轴后橡皮塞29 feed regulator shaft rubber cap | 1 | ||
| 53 | pfpc0153 | 倒缝架后孔橡皮塞23 climb device adjusting shaft rubber cap | 2 | ||
| 54 | pfpc0154 | 倒缝后支点橡皮塞20 feed adjusting shaft rubber cap | 1 | ||
| 55 | pfpc0155 | 后大橡皮塞26 arm back part rubber cap(large) | 1 | ||
| 56 | pfpc0149 | 后小橡皮塞11.8 arm back part rubber cap(middle) | 1 | ||
| 57 | pfpc0157 | 机壳后左橡皮塞8.8 arm back part rubber cap(small) | 4 | ||
| 58 | pfpc0151 | 机壳上左大橡皮塞19 arm back part rubber cap(large) | 1 | ||
| 59 | pfpc0157 | 挑线杆销橡皮塞8.8 arm back part rubber cap(small) | 1 | ||
| 60 | pfpc0160 | 夹线器组件 thread tension control ass'y | 1 | ||
| 61 | pfpc0161 | 夹线器防油圈 clamp oil ring | 1 | ||
| 62 | pfpc0162 | 松线钉 tension release pin | 1 | ||
| 63 | pf5550330 | 夹线器紧固螺钉 screw | 1 | ||
| 64 | pfpc0164 | 操作面板电线夹 cable holder | 2 | ||
| 65 | pf555016 | 操作面板电线夹螺钉 screw | 2 | ||
| 68 | pfq514102 | 绕线夹线器组件 wrap splitter assembly | 1 | ||
| 69 | pfpc0169 | 面板橡皮塞15.6 rubber cap | 2 | ||
| 70 | pfpc0170 | 孔塞 plug | 1 |
