01
02
02
03
03
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
24
26
27
28
29
30
30
30
30
31
31
31
31
32
33-1
33-2
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
430 用量 (number of 430 used) |
|---|---|---|---|---|---|
| 01 | pf9820a61 | 油盖 oil cap | 1 | ||
| 02 | pf1310a04 | 橡皮塞13.5 rubber cap, 13.5 | 3 | ||
| 03 | pf1310a05 | 橡皮塞10.5 rubber cap, 10.5 | 4 | ||
| 04 | pf430ga04 | 油盖 oil cap | 1 | ||
| 05 | pf430ga05 | 侧面盖板 frame side cover | 1 | ||
| 06 | pf8420m-d30846 | 螺钉m6x10 screw, pan m6x10 | 4 | ||
| 07 | pf430ga07 | 主面板 face plate | 1 | ||
| 08 | pf1310a11 | 橡皮塞15.5 rubber cap, 15.5 | 1 | ||
| 09 | pf8420m-d31415 | 螺钉m5x10 screw, pan m5x10 | 3 | ||
| 10 | pf430ga10 | 大旋梭盖 shuttle race cover | 1 | ||
| 11 | pf430ga11 | 大旋梭盖钩d shuttle race cover hook d | 1 | ||
| 12 | pf1310a16 | 螺钉m3x5 screw, flat m3x5 | 2 | ||
| 13 | pf1310a17 | 板螺母 nut plate | 1 | ||
| 14 | pf430ga14 | 段螺钉8-2 shoulder screw,8-2 | 2 | ||
| 15 | pf430ga15 | 弹簧垫圈 washer, wave spring | 2 | ||
| 16 | pf430ga16 | 大旋梭盖钩u shuttle race cover hook u | 1 | ||
| 17 | pf1310c248 | 螺钉m3x4 screw, pan m3x4 | 2 | ||
| 18 | pf1310j65 | 平垫圈m3 washer, plain m 3 | 2 | ||
| 19 | pf1310a23 | 挑线杆防护罩 thread take-up cover | 1 | ||
| 20 | pf1310a24 | 螺钉m4x10 screw, pan m4x10 |
1 | ||
| 24 | pf1310a02 | 开口销 dowel pin | 1 | ||
| 26 | ta2901 | 开关安装板 switch plate | 1 | ||
| 27 | pf430gr36sf3010398 | 大豪一体机开关 dahao switch | 1 | ||
| 28 | ta2902 | 后罩壳支柱螺钉 back cover support screw | 1 | ||
| 29 | pf1310j65 | 平垫圈 m3 washer ,plain m3 | 1 | ||
| 30 | pf7810749 | 平垫圈 washer | 4 | ||
| 31 | pf1310c252 | 螺栓m4x10 bolt, socket m4x10 | 4 | ||
| 32 | pf1790s0907 | 螺钉 screw | 1 | ||
| 33-1 | pf430gr37 | 电控大豪一体机(1000线电机按键屏幕)单踏板 | 1 | ||
| 33-2 | pf436gw23101 | 436g电控大豪一体机（1000线液晶屏电控） | 1 |
