01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
q7 用量 (number of q7 used) |
|---|---|---|---|---|---|
| 01 | pfq5f0201 | 上轴 main shaft | 1 | ||
| 02 | pfq60202 | 针杆曲柄 counter weight | 1 | ||
| 03 | pf5550625 | 挑线曲柄定位螺钉 screw | 4 | ||
| 04 | pf5550218 | 针杆曲柄紧固螺钉 screw | 1 | ||
| 05 | pf5550216 | 针杆曲柄定位螺钉 screw | 1 | ||
| 06 | pf5550217 | 针杆曲柄定位螺钉o型圈 o ring | 1 | ||
| 07 | pfq50207 | 上轴前轴套 front bushing of main shaft | 1 | ||
| 08 | pf555028 | 上轴中轴套 mid bushing of main shaft | 1 | ||
| 09 | pf555029 | 上轴中轴套螺钉 screw | 1 | ||
| 10 | pfq90a-90000210nak | 上轴油封 oil seal | 1 | ||
| 11 | pfq20205 | 上轴后套 rear bushing of main shaft | 1 | ||
| 12 | pfq7t016003 | 电机组件 motor | 1 | ||
| 13 | pfq5f0242 | 垫圈 the gasket | 1 | ||
| 14 | pfq7t01600301 | 电机定子 motor stator | 1 | ||
| 15 | pfq7t01600306 | 紧固螺钉 screw | 6 | ||
| 16 | pfq5022002 | 弹簧垫片 washer | 4 | ||
| 17 | scj2010 | 内六角圆柱头螺钉 screw | 4 | ||
| 18 | encoder asm. | 电机转子 motor rotor | 1 | ||
| 19 | pfq7t01600304 | 编码器 encoder asm. | 1 | ||
| 20 | pfq7t01600303 | 转子固定螺钉 screw | 2 | ||
| 21 | pfq7t01600307 | 孔塞 rubber plug | 1 | ||
| 22 | pf5550225 | 挑线杆铰链轴 threed take-up crank shaft | 1 | ||
| 23 | pf55500223a | 挑线杆部件 threed take-up asm. | 1 | ||
| 24 | pf5550228 | 挑线曲柄左螺钉 screw | 1 | ||
| 25 | pf555022404 | 滚针轴承 bearing | 2 | ||
| 26 | pf555031 | 针杆连杆 needle bar connecting rod | 1 | ||
| 27 | pf55502201 | 挑线杆曲柄 threed take-up shaft | 1 | ||
| 28 | pf55502212 | 挑线杆 threed take-up | 1 | ||
| 29 | pf55502211 | 挑线杆连杆 threed take-up connecting rod | 1 | ||
| 30 | pfq90a-55500223a01 | 挑线杆油封 gasket seale | 1 | ||
| 31 | pf68425h33 | 绕线主动轮紧定螺钉 screw | 2 | ||
| 32 | pf555022 | 挑线杆铰链轴紧固螺钉 screw | 1 | ||
| 33 | pf555026 | 上轴挡圈 retaining ring | 1 | ||
| 34 | scj1036 | 开口挡圈 retaining ring | 1 | ||
| 35 | pf03030223 | 绕线主动轮 wheel | 1 | ||
| 36 | pf5550212 | 曲柄油量调节销 the adjust pin | 1 | ||
| 37 | pf5550213 | 密封圈 side plate gasket | 1 | ||
| 38 | pf5550214 | 曲柄油量调节销o型圈 thrust collar asm | 1 | ||
| 39 | pfq90a0211 | 曲柄油量限制毡 oil felt | 1 | ||
| 40 | pfs5t0220 | 手轮 head wheel | 1 | ||
| 41 | pf1310b24 | 上轮螺钉 screw | 2 | ||
| 42 | pf90008129 | 螺钉 screw | 2 | ||
| 43 | pfs5t0228 | 手轮标牌 handwheel sign | 1 |
