61-1
02
03
04
05
06
07
08
09
10
11
12
13
24
16
17
18
21
22
23
24
25
26
27
28
29
31
32
33
34
35
36
37
38
39
40
41
42
42-1
43
44
45
46
49
50
51
53
54
56
57
58
59
60
61
62
63
64
65
66
14
14
14
17
05
06
28
28
05
38
39
30-2
61-2
68-1
68-2
69-1
69-2
70
71
72
73
30-3
30-1
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
q1 用量 (number of q1 used) |
|---|---|---|---|---|---|
| 01 | pfq531726083 | 夹线螺钉 screw | 1 | ||
| 02 | pfq512 | 面板垫face plate gasket | 1 | ||
| 03 | pf5550824 | 油窗oil window | 1 | ||
| 04 | pf5550825 | 油窗o型圈thrust collar asm | 1 | ||
| 05 | pf5550113 | 挑线连杆销螺孔塞rubber plug | 3 | ||
| 06 | pf5550112 | 针杆曲柄螺孔塞rubber plug | 2 | ||
| 07 | pf555016 | 后窗板螺钉screw 3/16x28 l=9 | 8 | ||
| 08 | pfq518 | 后窗板side plate | 1 | ||
| 09 | pfq519 | 后窗板垫side plate gasket | 1 | ||
| 10 | pfq5110 | 三眼线勾three eyeliner hook | 1 | ||
| 11 | pf5550114 | 送料调节器孔塞rubber plug | 1 | ||
| 12 | pf5550115 | 下轴盲孔塞rubber plug | 1 | ||
| 13 | pfs1t0113 | 型号牌model plate | 1 | ||
| 14 | pf555013 | 底板支柱bed screw stud | 4 | ||
| 16 | pf99901511 | 电线压板（短）cord holder(s) | 2 | ||
| 17 | pf5550161 | 电线压板固定螺钉screw 3/16x28 l=12 | 3 | ||
| 18 | pf99901160 | 电线压板（长）cord holder(l) | 1 | ||
| 21 | pfq1121 | 型号牌铆钉pole | 2 | ||
| 22 | pf90000131 | 绕线器紧固定螺钉screw 3/16x32 l=7 | 3 | ||
| 23 | pf90000132 | 绕线切刀thread cutter | 1 | ||
| 24 | pf68425k19 | 绕线切刀固定螺钉screw 1/8x40 l=4 | 2 | ||
| 25 | pf5550230 | 挑线杆护罩螺钉screw 3/16x28 l=6 | 1 | ||
| 26 | pf5550229 | 挑线杆护罩thread take-up lever cover | 1 | ||
| 27 | pf5550316 | 右线钩right arm thread guide | 1 | ||
| 28 | pf5550317 | 右线钩螺钉screw 11/64x40 l=6 | 3 | ||
| 29 | pf9520mxdk021 | 大线钩large arm thread guide | 1 | ||
| 31 | pf5550637 | 针板螺钉screw 11/64x40 l=8.5 | 2 | ||
| 32 | pfq50132 | 卷边器座ruler plate | 1 | ||
| 33 | pf5550117 | 卷边器座螺钉screw 11/64x40 l=5 | 2 | ||
| 34 | pf5550638 | 推板组件slide plate asm | 1 | ||
| 35 | pf555063801 | 推板slide plate | 1 | ||
| 36 | pf555063802 | 推板簧spring of slide plate | 1 | ||
| 37 | pf555063803 | 推板螺钉screw | 2 | ||
| 38 | pf5550161 | 面板螺钉 screw 3/16x28 l=12 | 3 | ||
| 39 | pf5550111 | 面板调节螺孔塞rubber plug | 2 | ||
| 40 | pfq50140 | 面板装饰牌plate | 1 | ||
| 41 | pfq5141 | 绕线夹线器组件bobbin thread tension asm | 1 | ||
| 42 | pf90000157 | 绕线器bobbin winder asm | 1 | ||
| 42-1 | pf900001511 | 绕线器油封oil seal | 1 | ||
| 43 | pfq1139 | 安全指示牌safety-indicating plate | 1 | ||
| 44 | pfq1190 | 电机罩组件pilley cover asm | 1 | ||
| 45 | pfq50145 | 电机罩组件固定螺钉screw m4 l=20 | 3 | ||
| 46 | pfq50146 | 电机罩组件固定螺钉垫片washer | 3 | ||
| 49 | pfq5149 | 支架固定螺钉screw m4 l=5.5 | 2 | ||
| 50 | pfq5150 | 支架 stand | 1 | ||
| 51 | pfq5151 | 操作面板顶紧螺钉screw m5 l=25 | 1 | ||
| 53 | pf98000187 | 调节孔孔塞rubber plug | 1 | ||
| 54 | pfq5129 | 左线钩left arm thread guide | 1 | ||
| 56 | pf9520mxdk02101 | 螺母 nut 11/64x40 | 1 | ||
| 57 | pf1310d239 | 地线紧固螺钉screw m4 | 1 | ||
| 58 | pf68425h33 | 二眼线钩螺钉screw | 1 | ||
| 59 | pf5550314 | 二眼线钩two-hole thread eyelet | 1 | ||
| 60 | pf5550330 | 夹线器螺钉screw | 1 | ||
| 61-1 | pfq531726 | 夹线器组件thread tension asm | 1 | ||
| 62 | pf5550330 | 松线钉thread release pin | 1 | ||
| 63 | pf5550334 | 松线辅钉弹簧tesnion release pin spring | 1 | ||
| 64 | pfq10153 | 垫片washer | 1 | ||
| 65 | pf5550333 | 卡圈 e-ring | 1 | ||
| 66 | pf90000329 | 松线辅钉 tesnion release supporting pin | 1 | ||
| 30-2 | pf0302141 | 针板 m2.6needle plate | 1 | ||
| 61-2 | pfq5h3172601 | 厚料大夹线器组件thread tension asm | 1 | ||
| 68-1 | pfq53172606 | 夹线簧 clamp spring | 1 | ||
| 68-2 | pfq5h3172606 | 夹线簧（厚料）clamp spring heavy | 1 | ||
| 69-1 | pfq53172606 | 挑线簧 take up spring | 1 | ||
| 69-2 | pfq5h3172606 | 挑线簧 （厚料）take up spring heavy | 1 | ||
| 70 | pfq53172608 | 夹线螺母 tension nut | 1 | ||
| 71 | pfq53172605 | 松线板 tension disc holder | 1 | ||
| 72 | pfq53172604 | 夹线板 tension disc | 1 | ||
| 73 | pfq531726083 | 夹线螺钉 screw | 1 | ||
| 30-3 | pf90010140h | 针板 m2.4needle plate | 1 | ||
| 30-1 | pf5550636 | 针板 m1.9needle plate | 1 |
