01
02-1
02-2
03
04
05
06-1
06-2
07
07
07
08
09
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
| 操作 (operation) |
数量 (quantity) |
零件编号 (number) |
零件品号 (product number) |
零件名称 (product name) |
8420d-3 用量 (number of 8420d-3 used) |
8420d-5 用量 (number of 8420d-5 used) |
8720d用量 (number of 8720d used) |
|---|---|---|---|---|---|---|---|
| 01 | 033102002 | 机头 arm | 1 | 1 | 1 | ||
| 02-1 | 034203008 | 底板（d3剪线款) bed | 1 | 1 | 1 | ||
| 02-2 | 034203005 | 底板（d普通款) bed | 1 | 1 | 1 | ||
| 03 | pf8420m-d3010103 | 带槽销 dowel pin | 2 | 2 | 2 | ||
| 04 | pf68425a02 | 定位销 positioning pin | 1 | 1 | 1 | ||
| 05 | pf8420m-d301010501l | 面板 face plate | 1 | 1 | 1 | ||
| 06-1 | bz3137 | 面板商标牌（分体机）plate | 1 | 1 | 1 | ||
| 06-2 | bz3138 | 面板商标牌（一体机）plate | 1 | 1 | 1 | ||
| 07 | pf8420m-d3010107 | 橡皮塞 rubber cap,15.5 | 2 | 2 | 2 | ||
| 08 | pf8420m-d3010110 | 螺钉m5×8 screw | 2 | 2 | 2 | ||
| 09 | pf8420m-d301010901l | 后盖板 rear cover | 1 | 1 | 1 | ||
| 10 | pf8420m-d3010110 | 螺钉m5×14 screw | 7 | 7 | 7 | ||
| 11 | pf8420m-d3010111 | 防尘板 dust protector | 1 | 1 | 1 | ||
| 12 | pf8420m-d3010112 | 螺钉m5×6 screw | 2 | 2 | 2 | ||
| 13 | pf8420m-d3010113 | 长脚柱 bed leg,l | 1 | 1 | 1 | ||
| 14 | pf8420m-d3010114 | 短脚柱 bed leg,s | 1 | 1 | 1 | ||
| 15 | pf8420m-d3010115 | 左推板组件 slide plate,la assy | 1 | 1 | 1 | ||
| 16 | pf8420m-d3010116 | 左推板 slide plate,la | 1 | 1 | 1 | ||
| 17 | pf8420m-d3010117 | 推板窗 bobbin window | 1 | 1 | 1 | ||
| 18 | pf8420m-d3010118 | 右推板组件 slide plate assy,r | 1 | 1 | 1 | ||
| 19 | pf8420m-d3010119 | 右推板 slide plate,r | 1 | 1 | 1 | ||
| 20 | pf8420m-d3010120 | 前推板组件 slide plate f assy | 1 | 1 | 1 | ||
| 21 | pf8420m-d3010121 | 前推板 slide plate,f | 1 | 1 | 1 | ||
| 22 | pf8420m-d3010122 | 前推板定位块（左） | 1 | 1 | 1 | ||
| 23 | pf8420m-d3010123 | 前推板定位块（右） | 1 | 1 | 1 | ||
| 24 | pf8420m-d3010124 | 螺钉sm1/8×40x4 screw sm1/8×40x4 | 4 | 4 | 4 | ||
| 25 | pf68425a16 | 螺钉m5×4 screw m5×4 | 1 | 1 | 1 | ||
| 26 | bz3122 | 接地标记 label grounding | 1 | 1 | 1 | ||
| 27 | bz3141 | ce标记 label ce | 1 | 1 | 1 | ||
| 28 | pf8420m-d301012802 | 马达罩(新）motor cover | 1 | 1 | 1 | ||
| 29 | pf9990423 | 螺钉m5x14 screw pan m5x14 | 3 | 3 | 3 | ||
| 30 | pf8420m-d31415 | 螺钉m5x10 screw pan m5x10 | 1 | 1 | 1 |
